Hand Chamfering Tool
Model :
SA88100AL/ SA88100RL
SA88100AL C Angle
SA88100RL C & R Angle
Hand Chamfering Tool
● Free Speed: 30,000 RPM
● Height: 65 mm
● Sound Level: 81 dB(A)
● Chanferring Capacity:
Steel & Alum. & Brass: C0.1 - C2.0 mm (=13 Gauge)
Stainless steel: C0.1 - C1.2 mm (=18 Gauge)
SA88100RL C & R Angle
Hand Chamfering Tool
● Free Speed: 30,000 RPM
● Height: 65 mm
● Sound Level: 81 dB(A)
● Chanferring Capacity:
Steel & Alum. & Brass: C0.1 - C2.0 mm (=13 Gauge)
Stainless steel: C0.1 - C1.2 mm (=18 Gauge)
SA88100AL
SA88100RL
SA88100AL C Angle
SA88100RL C & R Angle
Hand Chamfering Tool
SA88100RL C & R Angle
Hand Chamfering Tool
|
Model No. |
Air Cons. |
Free |
Net |
Overall |
Air Inlet |
Air |
Hose |
|||||
|
耗氣量 |
無負載轉速 |
重量 |
長度 |
進氣口 |
空氣壓力 |
氣管尺寸 |
||||||
|
CFM |
L/min |
RPM / SPM |
lb |
kg |
Inch |
mm |
NPT(PT) |
psi |
bar |
Inch |
mm |
|
|
SA88100AL(RL) |
2.3 |
65 |
30,000 |
1.01 |
0.46 |
5.51 |
140 |
1/4" |
90 |
6.2 |
3/8 |
10 |
SA88100AL C Angle
SA88100RL C & R Angle
Hand Chamfering Tool
SA88100RL C & R Angle
Hand Chamfering Tool
