Air Hose Reel
Air Hose Reel
● Casing made strong ABS plastic
● Automatic hose reel, Ratchet or free-running operation
● Lightweight and corrosion resistant design
● Plastic protector protects hose against damage when pulled and/ or stretched.
● Supplied with wall/ ceiling mounted bracket.
● Rewind spring: Strong steel spring automatically rewinds hose after catch is released.
● Mounting bracket: 180 degree rotation , can be fixed on wall or ceiling.
● Working temperature -5ºC~+ 60ºC
● Single packaging: 345 x 300 x 145 mm
● Measurement: 6 sets in a master carton, 610 x 355 x 450 mm(L x W x H).
Air Hose Reel
● Supplied with mounting bracket.
● Case standard color: Yellow
● Hose standard color: Yellow
|
Model No. |
Hose I.D |
Max.Working |
Bursting |
Inlet |
Outlet |
Hose |
Thread |
Weight |
|||
|
mm |
inch |
psi |
bar |
psi |
bar |
cm |
m |
in + outlet |
kg |
||
|
HR12UB6508 |
6.5 |
1/4 |
218 |
15 |
870 |
60 |
50 |
8 |
PU Braid |
1/4 + 1/4 |
3.3 |
|
HR12UB6510 |
6.5 |
1/4 |
218 |
15 |
870 |
60 |
50 |
10 |
PU Braid |
1/4 + 1/4 |
3.3 |
|
HR12UB6512 |
6.5 |
1/4 |
218 |
15 |
870 |
60 |
50 |
12 |
PU Braid |
1/4 + 1/4 |
3.3 |
|
HR12UB8008 |
8.0 |
5/16 |
218 |
15 |
870 |
60 |
50 |
8 |
PU Braid |
1/4 + 1/4 |
3.3 |
Air Hose Reel
● Works with suitable pneumatic tools
● Used for automotive maintenance, home DIY and/ or manufacturing
facilities.
