18V Brushless Cordless Riveter
SERG1800V-003plus 5,000 lbs
SERG1800V-004 2,500 lbs
18V Brushless Cordless Riveter
w/ 18V Li-ion Battery
● The Most Efficient Riveting Tool, With 2.2secs (SERG1800V-003) & 1.2secs (SERG1800V-004)
Could Finish The Work. Which Is From Pull Rivet Until Discharge Mandrel.
SERG1800V-003plus 5,000 lbs
SERG1800V-004 2,500 lbs
18V Brushless Cordless Riveter
w/ 18V Li-ion Battery
Contents:
● 1PC 100~240V (50~60Hz) 65W Lithum Charger
● 2PCS 2.6Ah Lithum Battery (Panasonic)
● 1PC Blow Molded Case
|
Model No. |
Force |
Stroke |
Drive |
Battery |
Tool Dimensions |
Riveting Capacity |
||||
|
lbs |
N |
mm |
- |
Li - Ion |
H |
L |
D |
Weight |
mm (inch) |
|
|
SERG1800V-003 |
5,000 |
22,241 |
25 |
Brushless DC |
18V |
306.2mm |
307.3mm |
70.5mm |
1.69kg |
Φ3.2(1/8")~Ø6.4(1/4") |
|
SERG1800V-003plus |
Ø2.4(3/32")~Ø6.4(1/4") |
|||||||||
|
SERG1800V-004 |
2,500 |
11,120 |
25 |
Brushless DC |
18V |
306.2mm |
307.3mm |
70.5mm |
1.69kg |
Ø2.4(3/32")~Ø4.8(3/16") |
Optional
SERG1800V-003plus 5,000 lbs
SERG1800V-004 2,500 lbs
18V Brushless Cordless Riveter
w/ 18V Li-ion Battery
