1-1/2" Heavy Duty Air Clean/ Dryer
FD160-M112 Milton Type
FD160-O112 Orion Type
1-1/2" Heavy Duty Air Clean/ Dryer
● Aluminum alloy body: Light weight and better corrosion resistance.
● High air flow and low pressure drop.
● Indicator (FD160): Red indicator will rise when filter element needs to be changed (pic 1).
● User can check the water level from ullage scale.
● No steel material used and no rust will happen.
● FD160: ISO 8573-1:2010 [1:7:2]
FD160-M112 Milton Type
FD160-O112 Orion Type
1-1/2" Heavy Duty Air Clean/ Dryer
● Material: Aluminum
● Working Temperature: 5~60º C
● Rated Flow (Max).
● Blocking Display Stick
|
Iteml No. |
Type |
Port Size |
Thread |
Working |
Filter |
Drain |
Drain |
Flow |
|
|
PT/ NPT/ G |
psi |
bar |
μ |
L/min |
|||||
|
FD160-N112 |
Nitto |
1-1/2" |
PT |
225 |
15.5 |
0.01 |
Manual |
450 ml |
12000 |
|
FD160-M112 |
Milton |
1-1/2" |
NPT |
225 |
15.5 |
0.01 |
Manual |
450 ml |
12000 |
|
FD160-O112 |
Orion |
1-1/2" |
G |
225 |
15.5 |
0.01 |
Manual |
450 ml |
12000 |
